<?php
// This file is part of Moodle - http://moodle.org/
//
// Moodle is free software: you can redistribute it and/or modify
// it under the terms of the GNU General Public License as published by
// the Free Software Foundation, either version 3 of the License, or
// (at your option) any later version.
//
// Moodle is distributed in the hope that it will be useful,
// but WITHOUT ANY WARRANTY; without even the implied warranty of
// MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
// GNU General Public License for more details.
//
// You should have received a copy of the GNU General Public License
// along with Moodle. If not, see <http://www.gnu.org/licenses/>.
/**
* Chart base.
*
* @package core
* @copyright 2016 Frédéric Massart - FMCorz.net
* @license http://www.gnu.org/copyleft/gpl.html GNU GPL v3 or later
*/
namespace core;
defined('MOODLE_INTERNAL') || die();
use coding_exception;
use JsonSerializable;
use renderable;
/**
* Chart base class.
*
* @package core
* @copyright 2016 Frédéric Massart - FMCorz.net
* @license http://www.gnu.org/copyleft/gpl.html GNU GPL v3 or later
*/
class chart_base implements JsonSerializable, renderable {
/** @var chart_series[] The series constituting this chart. */
protected $series = [];
/** @var string[] The labels for the X axis when categorised. */
protected $labels = [];
/** @var string The title of the chart. */
protected $title = null;
/** @var chart_axis[] The X axes. */
protected $xaxes = [];
/** @var chart_axis[] The Y axes. */
protected $yaxes = [];
/** @var array Options for the chart legend. */
protected $legendoptions = [];
/**
* Constructor.
*
* Must not take any argument.
*
* Most of the time you do not want to extend this, rather extend the
* method {@link self::set_defaults} to set the defaults on instantiation.
*/
public function __construct() {
$this->set_defaults();
}
/**
* Add a series to the chart.
*
* @param chart_series $serie The serie.
*/
public function add_series(chart_series $serie) {
$this->series[] = $serie;
}
/**
* Serialize the object.
*
* @return array
*/
public function jsonSerialize() {
global $CFG;
return [
'type' => $this->get_type(),
'series' => $this->series,
'labels' => $this->labels,
'title' => $this->title,
'axes' => [
'x' => $this->xaxes,
'y' => $this->yaxes,
],
'legend_options' => !empty($this->legendoptions) ? $this->legendoptions : null,
'config_colorset' => !empty($CFG->chart_colorset) ? $CFG->chart_colorset : null
];
}
/**
* Get an axis.
*
* @param string $type Accepts values 'x' or 'y'.
* @param int $index The index of this axis.
* @param bool $createifnotexists Whether to create the axis if not found.
* @return chart_axis
*/
private function get_axis($type, $index, $createifnotexists) {
$isx = $type === 'x';
if ($isx) {
$axis = isset($this->xaxes[$index]) ? $this->xaxes[$index] : null;
} else {
$axis = isset($this->yaxes[$index]) ? $this->yaxes[$index] : null;
}
if ($axis === null) {
if (!$createifnotexists) {
throw new coding_exception('Unknown axis.');
}
$axis = new chart_axis();
if ($isx) {
$this->set_xaxis($axis, $index);
} else {
$this->set_yaxis($axis, $index);
}
}
return $axis;
}
/**
* Get the labels of the X axis.
*
* @return string[]
*/
public function get_labels() {
return $this->labels;
}
/**
* Get an array of options for the chart legend.
*
* @return array
*/
public function get_legend_options() {
return $this->legendoptions;
}
/**
* Get the series.
*
* @return chart_series[]
*/
public function get_series() {
return $this->series;
}
/**
* Get the title.
*
* @return string
*/
public function get_title() {
return $this->title;
}
/**
* Get the chart type.
*
* @return string
*/
public function get_type() {
$classname = get_class($this);
return substr($classname, strpos($classname, '_') + 1);
}
/**
* Get the X axes.
*
* @return chart_axis[]
*/
public function get_xaxes() {
return $this->xaxes;
}
/**
* Get an X axis.
*
* @param int $index The index of the axis.
* @param bool $createifnotexists When true, create an instance of the axis if none exist at this index yet.
* @return chart_axis
*/
public function get_xaxis($index = 0, $createifnotexists = false) {
return $this->get_axis('x', $index, $createifnotexists);
}
/**
* Get the Y axes.
*
* @return chart_axis[]
*/
public function get_yaxes() {
return $this->yaxes;
}
/**
* Get a Y axis.
*
* @param int $index The index of the axis.
* @param bool $createifnotexists When true, create an instance of the axis if none exist at this index yet.
* @return chart_axis
*/
public function get_yaxis($index = 0, $createifnotexists = false) {
return $this->get_axis('y', $index, $createifnotexists);
}
/**
* Set the defaults for this chart type.
*
* Child classes can extend this to set default values on instantiation.
*
* In general the constructor could be used, but this method is here to
* emphasize and self-document the default values set by the chart type.
*
* @return void
*/
protected function set_defaults() {
}
/**
* Set the chart labels.
*
* @param string[] $labels The labels.
*/
public function set_labels(array $labels) {
$this->labels = $labels;
}
/**
* Set options for the chart legend.
* See https://www.chartjs.org/docs/2.7.0/configuration/legend.html for options.
*
* Note: Setting onClick and onHover events is not directly supported through
* this method. These config options must be set directly within Javascript
* on the page.
*
* @param array $legendoptions Whether or not to display the chart's legend.
*/
public function set_legend_options(array $legendoptions) {
$this->legendoptions = $legendoptions;
}
/**
* Set the title.
*
* @param string $title The title.
*/
public function set_title($title) {
$this->title = $title;
}
/**
* Set an X axis.
*
* Note that this will override any predefined axis without warning.
*
* @param chart_axis $axis The axis.
* @param int $index The index of the axis.
*/
public function set_xaxis(chart_axis $axis, $index = 0) {
$this->validate_axis('x', $axis, $index);
return $this->xaxes[$index] = $axis;
}
/**
* Set an Y axis.
*
* Note that this will override any predefined axis without warning.
*
* @param chart_axis $axis The axis.
* @param int $index The index of the axis.
*/
public function set_yaxis(chart_axis $axis, $index = 0) {
$this->validate_axis('y', $axis, $index);
return $this->yaxes[$index] = $axis;
}
/**
* Validate an axis.
*
* We validate this from PHP because not doing it here could result in errors being
* hard to trace down. For instance, if we were to add axis at keys without another
* axis preceding, we would effectively contain the axes in an associative array
* rather than a simple array, and that would have consequences on serialisation.
*
* @param string $xy Accepts x or y.
* @param chart_axis $axis The axis to validate.
* @param index $index The index of the axis.
*/
protected function validate_axis($xy, chart_axis $axis, $index = 0) {
if ($index > 0) {
$axes = $xy == 'x' ? $this->xaxes : $this->yaxes;
if (!isset($axes[$index - 1])) {
throw new coding_exception('Missing ' . $xy . ' axis at index lower than ' . $index);
}
}
}
}
